PUMP DESCRIPTION
Pumping of clean water for domestic, industrial, agricultural and gardening purposes. Suitable for applications like water transfer, sprinkler or drip irrigation, domestic booster or booster sets. Silent....
Couldn't load pickup availability
PUMP DESCRIPTION
Pumping of clean water for domestic, industrial, agricultural and gardening purposes. Suitable for applications like water transfer, sprinkler or drip irrigation, domestic booster or booster sets. Silent. Self-priming up to 2m
| Maximum height (m) | 67 |
|---|---|
| Maximum flow (m3/h) | 7 |
| Voltage (V) | 230 |
| Frequency (Hz) | 50 |
| Input power P1 (kW) | 2.2 |
| Intensity (A) | 9.800000000000001 |
| Capacitor capacity | 30µF-450V |
| Pressure range (m) | 67-26 |
| Motor power P2 (kW) | 1.5 |
| Maximum working pressure (bar) | 12 |
| Number of motor phases | single-phase |
| Number of poles | 2 |
| Number of impellers | 6 |
| On/off switch | No |
| Plug type | without plug |
| Minimum flow (m3/h) | 0.7 |
| Electrical features | |||
|---|---|---|---|
| Electrical isolation | F Class | Protection rating | IPX5 |
| Motor type | Asynchronous | Service factor | S1 |
| Limitations | |||
|---|---|---|---|
| Maximum suction (m) | 2 | Water temperature (ºC) | Max: 40 |
| Materials | |||
|---|---|---|---|
| Mechanical seal | Aluminium-Graphite | Suction body | Cast iron |
| Pump body | Stainless steel AISI 304 | Discharge body | Cast iron |
| Diffuser/s | Technopolymer | Pump shaft | Stainless steel AISI 420 |
| Motor casing | Aluminium | Impeller/s | Stainless steel AISI 304 |
| O-rings | NBR/EPDM | ||
| Manufacturing features | |||
|---|---|---|---|
| Suction diameter | 1" | Discharge diameter | 1" |
| Motor cooling | Fan | Seal type | Mechanical seal |
| Suction connection type | Thread | Discharge connection type | Thread |
